Standard Duty, Eccentric Locking Collar Type
- Standard duty anti-rotation device
- Spherical OD self-aligns in outer housing
- Eccentric locking collar
- Wide inner ring bearing
- Lubrication groove with hole on set screw side
- Additional oil hole on opposite side
- Dual seals
- Triple lip seals (R3 suffix) optional
- Also available in free-spinning design and/or with black oxide finish
| Specifications: | |
|---|---|
| Unit No. | HC204-12 |
| Bearing Type | Standard duty, eccentric locking collar |
| Material | AISI 52100 |
| Shaft Diameter | 0.7500 in |
| Outer Diameter | 1.8504 in |
| Width | 1.7205 in |
| Outer Ring Width | 0.6693 in |
| Dynamic load ratings | 2877.55 lbs |
| Static load ratings | 1494.98 lbs |
