UCPX Series - Medium Duty, Set Screw Locking Type
- Medium duty unit, set screw locking
- One-piece cast iron housing, solid base
- Wide inner ring bearing
- Dual heavy-duty slinger type contact seals
- Grease fitting for adding lubricant
- Triple lip seals available on request
| Specifications: | |
|---|---|
| Unit No. | UCPX06-20 |
| Bearing Type | Pillow Block - Medium duty unit, set screw locking |
| Material | Cast Iron Housing, AISI 52100 steel insert |
| Shaft Diameter | 1.2500 in |
| Insert No. | UCX06-20 |
| Housing No. | PX06 |
| Basic Dynamic Load Rating (Cr) | 5777.59 lbs |
| Basic Static Load Rating (Cor) | 3439.58 lbs |
| Weight | 4.41 lbs |
