UCPK Series - Standard Duty, Low Center Height, Set Screw Locking Type
- Standard duty unit with low center height
- Set screw locking
- One-piece cast iron housing
- Wide inner ring bearing
- Dual heavy-duty slinger type contact seals
- Grease fitting for adding lubricant
- Anti-Rotation device
- Triple lip seals available on request
| Specifications: | |
|---|---|
| Unit No. | UCPK206-18 |
| Bearing Type | Pillow Block - Standard duty unit with low center height, set screw locking |
| Material | Cast Iron Housing, AISI 52100 steel insert |
| Shaft Diameter | 1.1250 in |
| Insert No. | UC206-18 |
| Housing No. | PK206 |
| Basic Dynamic Load Rating (Cr) | 4383.77 lbs |
| Basic Static Load Rating (Cor) | 2540.34 lbs |
| Weight | 2.87 lbs |
